ELLE Shear Baler

LOADING – UNLOADING

The ELLE Shear Baler is perfect for loading and unloading and are suitable for users who need to move frequently or rent them to third parties.

Info Sheet
Product Details
Videos
Related Products

Product Details

KEY FEATURES
  • OVERSTROKE ON EACH WING (patented)
  • “ECA” cutting stroke economizer
  • “HP” Working cycle economizer
  • “CSA” cylinder and stroke dampers
  • “TS” teleservice
  • CETOP STANDARD VALVES
  • Soft starter
  • Automatic lubrification of the hinges*
  • Automatic lubrification system
  • External, independent filtering circuit
  • Remote control
  • “IRO” indipendent oil heating system*
  • Loading hopper*
  • Safety kit*
  • … AND MORE
    * on request
Categories ,
×
u/m L662 L762 L873 L973
Cutting force tons 600 700 800 900
Clamp * * * *
Bale dimension mm 900x600 900x600 900x600 900x600
Open box width mm 2800 2800 2800 2800
Box length mm 6100 6100 7200 7200
Cylinder per wing n. 2 2 3 3
Max. compression force (each wing) tons 300 300 450 450
Main cylinder compression force tons 150 150 150 150
Diesel engine hp 280 280 400 400
Indicative weight tons 80 85 100 105
Lifting Jacks n. 4+2 4+2 4+2 4+2
The ELLE Shear Baler work simply resting on the ground and are easy to position and start up. These shear and balers can produce bales that are automatically ejected. The ELLE transportable shear balers are equipped with 4 lifting cylinders to allow loading and unloading from the transport vehicle (the maximum lifting height is 1100 mm). The supporting structure is fitted with 2 additional rear cylinders to ensure stability and alignment to the ground. The ELLE Shear Baler line is equipped with the original TAURUS swinging wing compression system with OVERSTROKE on both wings SBxc (patented).
