75 Series

Primary shredders 75 series are designed for processing various wood waste (green and dry wood, tree roots, pallets) cable spools, tires, household, railway sleepers, telephone poles and C&D waste.

75_Series

default

Product Details

KEY FEATURES

Capacity up to 60 t/h (depends on material)
Remote control
Hydraulic conveyor
Mobility
Reverse shafts mode
ESD System
Durable shredding parts

ADDITIONAL EQUIPMENT

Overbelt Magnet
Water Sprinkling System
Reversible Fans For Radiator Cleaning
System of sieves or sifters to separate the materials by size
Additional Conveyors
Modification and installation of equipment according to the customer’s needs
For 75 E – current generator
Industry 4.0 – Special module provides remote performance analysis, customer feedback and troubleshooting worldwide

Category Olnova

×

MATERIAL	OUTPUT T/H
Light Mixed Scrap	10
White Goods	10
Industrial Waste	45
Old Wood	60
Household Waste	50
Cable Drums	40
Pallets	50
Railway Sleepers	25
Green Waste	30
Root Stems	35
Bulky Waste	30
Paper Rolls	15
Old Tires	20
Aluminium	12
Engine Blocks	5

×

MODEL	VB 75 DK	VB 75 D	VB 75 E
Type	mobile on tracks	hooklift	stationary
Drive	diesel engine	diesel engine	two electric motors
Power	380/283 hp/kW	380/283 hp/kW	2x132 hp/kW
Output	15-60 t/h	15-60 t/h	15-60 t/h
Input Material Size	2500 - 5000 mm	2500 - 5000 mm	2500 - 5000 mm
Output Material Size	150 - 400 mm	150 - 400 mm	150 - 400 mm
Shafts Speed	23-43 rpm	23-43 rpm	23-43 rpm
Discharge Material Height	5300 mm	3400 mm	5300 mm
Transportation Width	2500 mm	2500 mm	2500 mm
Transportation Height	2870 mm	2870 mm	2870 mm
Transportation Length	11360 mm	11360 mm	11360 mm
Operational Length	9710 mm	9710 mm	9710 mm
Controls	radio remote	radio remote	radio remote
Weight	22 t	19 t	20 t
