*Depends on shredder's equipment, a shaft configuration and material infeed. Provided performance data is an average value without a guarantee.
MATERIAL | OUTPUT T/H |
---|---|
C&D Waste | 80 - 100 |
Concrete | 60 - 80 |
Asphalt | 60 - 80 |
Wood Waste | 10 |
Biomass | 20 |
Plastic Waste | 15 |
MODEL | |
---|---|
Type | mobile on tracks |
Drive | diesel engine |
Power | 175/129 hp/kW |
Shafts Speed | 20-40 rpm |
Discharge Material Height | 2300 mm |
Transportation Width | 2300 mm |
Transportation Height | 2722 mm |
Transportation Length | 6616 mm |
Operational Length | 8162 mm |
Weight | 15 t |
Shaft Length | 1500 mm |
Shaft Diameter | 680 mm |
Shaft Weight | 2000 kg/cassette |
