85 Series

Primary shredders 85 series are designed for shredding different types of waste: industrial waste, municipal waste, mixed waste, wood waste, paper rolls, stones, tires, bulky waste, C&D waste, railway sleepers and car bodies.

85_Series

s_85_1

Product Details

KEY FEATURES

High performance
Mobility
Emergency Stop System
Remote control
Reverse shafts mode
Durable shredding parts
Hydraulic conveyor

ADDITIONAL EQUIPMENT

Overbelt Magnet
System of sieves and sifters to separate materials by size
Conveyors
Water Sprinkling System
Reversible Fans For Radiator Cleaning
Modification and installation of the equipment according to the customer’s needs
Industry 4.0 – Special module provides remote performance analysis, customer feedback and troubleshooting worldwide

Category Olnova

×

MATERIAL	OUTPUT T/H
Mixed Waste	100
Industrial Waste	80
Old Wood	60
Construction Waste	80
Cable Drums	90
Railway Sleepers	50
Tree Roots	60
Bulky Waste	60
Paper Rolls	30
Old Tires	30
Aluminum Waste	20
Car Bodies	20-30

×

MODEL	VB 85 DK	VB 85 D	VB 85 E
Type	mobile on tracks	stationary	stationary
Drive	diesel engine	diesel engine	two electric motors
Power	480/358 hp/kW	480/358 hp/kW	429/320 hp/kW
Output	20-100 t/h	20-100 t/h	20-100 t/h
The volume of the bunker	3,5 m³	3,5 m³	3,5 m³
Input Material Size	2500 - 5000 mm	2500 - 5000 mm	2500 - 5000 mm
Output Material Size	150 - 400 mm	150 - 400 mm	150 - 400 mm
Shafts Speed	23-43 rpm	23-43 rpm	23-43 rpm
Discharge Material Height	3700 mm	3700 mm	3700 mm
Transportation Width	2800 mm	2800 mm	2800 mm
Transportation Height	3120 mm	3120 mm	3120 mm
Transportation Length	8027 mm	8027 mm	8027 mm
Operational Length	9710 mm	9710 mm	9710 mm
Controls	radio remote	radio remote	radio remote
Weight	35 t	27 t	30 t
